SY3137 48V POE Surge Protective with 5KA 8 to 20μs Max Current and 100Mb/s Data Rate
Product Details:
| Place of Origin: | Fujian, China |
| Brand Name: | SY |
| Model Number: | SY3137 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pieces |
|---|---|
| Price: | $6.60/pieces >=5 pieces |
|
Detail Information |
|||
| Type: | T1 | Rated Voltage: | 48V |
|---|---|---|---|
| Max Discharge Current: | 10 A | Line Voltage: | 5V |
| Operating Voltage: | 6.8v | Max Current: | 5KA(8 To 20μs) |
| Data Rate: | 100Mb/s | Connection: | Ethernet, RJ 45 Cat6 |
| Protected Pins: | (1,2)(3,6)(4,5)(7,8) | Shell Material: | ABS |
Product Description
SY3137 network arrester lightning rj45
1. Specification details
| Model | SY3137 |
| Interface | Ethernet, RJ45 Cat6 |
| Data rate | 100Mb/s |
| Line voltage | 5V |
| Operating voltage | 6.8V |
| Max urge discharge current | 5KA(8-20 μ s) |
| Protected pins | (1,2)(3,6)(4,5)(7,8) |
| Mounting | Grounding clip & Grounding terminal |
| Shell material | ABS |
| Weight | 52g |
| Size | 26*26*95mm |
| Package inch | 40*27*105mm |
2. Dimensions
3.Main feature:
--ABS material profile shell, attractive and durable, good shielding effect;
--RJ 45 convenient to use, reliable connection;
--Introducing multilayer protection circuit, selecting the latest high-speed surge protection device of quick response, low output residual voltage and super transmission performance.
4.Package
Surge protector x 1
Grounding terminal/Grounding clip x 1
Manuals/Instructions x 1
5.Certificates
CE / ROHS / Lead-free
Welcome your inquiry, we will do our best to support you!
If there is other requirements for surge protector, pls send your specs, we will design for you!
Want to Know more details about this product
