Line Voltage 48V DC Surge Protector for RJ45 Signals Protect Your Network Effectively
Product Details:
| Place of Origin: | Fujian, China |
| Brand Name: | SY |
| Model Number: | SY3158 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | $7.00/pieces |
|
Detail Information |
|||
| Line Voltage: | POE 48V DC | Max Continuous Operating Voltage: | POE 90V |
|---|---|---|---|
| Data Rate: | 10/100Mb/s | Max Current: | 5KA (8 To 20μs) |
| Connection: | Ethernet, RJ 45 Cat6 With POE | Protected Pins: | All Pins |
| Shell Material: | ABS | Size: | 26*26*95mm |
| Weight: | 52g | Mounting: | Grounding Clip & Grounding Terminal |
Product Description
SY3158 china electronic rj45 signal surge protector lightning arrester
1.Specification details
| Model | SY3158 poe 48v surge protector rj45 |
| Interface | Ethernet, RJ45 Cat6, with POE |
| Data rate | 10/100Mb/s |
| Line voltage | POE 48V DC |
| Max operating voltage | POE 90V |
| Max surge discharge current | 5KA (8-20 μ s) |
| Protected pins | All pins |
| Mounting | Grounding clip & Grounding terminal |
| Shell material | ABS |
| Weight | 52g |
| Size | 26*26*95mm |
| Package inch | 40*27*105mm |
2. Dimensions
3.Main feature:
--ABS material profile shell, attractive and durable, good shielding effect;
--RJ 45 convenient to use, reliable connection;
--Introducing multilayer protection circuit, selecting the latest high-speed surge protection device of quick response, low output residual voltage and super transmission performance.
4. Package
Surge protector x 1
Grounding terminal/ Grounding clip x 1
Manuals/ Instructions x 1
5.Certificates
CE certificate
Compliant to ROHS
Lead-free
6.Service
A. OEM
B. If there is other requirements, pls send your specs, we will design for you.
Welcome your inquiry, we will do our best to support you!
