POE RJ45 Surge Protective Device Rated 5V and Max Current 5KA 8 to 20μs for Standards
Product Details:
| Place of Origin: | Fujian, China |
| Brand Name: | SY |
| Model Number: | SY3138 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pieces |
|---|---|
| Price: | $6.60/pieces >=5 pieces |
|
Detail Information |
|||
| Type: | T1 | Rated Voltage: | 5V |
|---|---|---|---|
| Max Discharge Current: | 20 A | Line Voltage: | 48V |
| Operating Voltage: | POE 75V | Connection: | Ethernet, RJ 45 Cat6 With POE |
| Data Rate: | 100Mb/s | Max Current: | 5KA(8 To 20μs) |
| Protected Pins: | (1,2)(3,6)(4,5)(7,8) | Others: | Available In GigE,10/100BT&DSL |
| Weight: | 70g | ||
Product Description
Surge Protective Device/ SPD / RJ45 surge protector with POE SY3138
RJ45 surge protector is special used in the network system and its different types can satisfy different defence thunder areas. The connector of its input and output is RJ45 male/female connector, which is easily connected and installed. It is main used in service equipment, inner LAS and HuB, and boardband RJ45 interface protection for protecting the equipment which will be damaged by the over voltage of the earth or the line inductance.
RJ45 surge protector SY3138 with POE is one of the surge protector using in protection for network.
1. Specification details
| Model | SY3138 |
| Interface | Ethernet, RJ45 Cat6, with POE |
| Data rate | 1000Mb/s |
| Line voltage | 48V |
| Max operationg voltage | POE 75V |
| Max surge discharge current | 5KA(8-20 μ s) |
| Protected pins | (1,2)(3,6)(4,5)(7,8) |
| Mounting | Grounding clip & Grounding terminal |
| Shell material | ABS |
| Weight | 70g |
| Size | 26*26*95mm |
| Package inch | 40*27*105mm |
2. Dimensions
3.Main feature:
1.ABS material profile shell, attractive and durable, good shielding effect;
2.RJ 45 convenient to use, reliable connection;
3.Introducing multilayer protection circuit, selecting the latest high-speed surge protection device of quick response, low output residual voltage and super transmission performance.
4.Package
Surge protector x 1
Grounding terminal/Grounding clip x 1
Manuals/Instructions x 1
5.Certificates
CE / ROHS / Lead-free
6.Service
A. OEM
B. If there is other requirements for surge protector, pls send us your specs, we will design for you!
Welcome your inquiry, we will do our best to support you!
